Verified Top Loading Balance (Capacity 420g Internal Cal) UW420H-V

Save 21%
Verified Top Loading Balance (Capacity 420g Internal Cal) UW420H-V

Verified Top Loading Balance (Capacity 420g Internal Cal) UW420H-V

Original price was: £1,131.00.Current price is: £889.00.

(£1,066.80 inc VAT)

SKU: UW420H-V Categories: ,

Verified, Class ll for trade use
Capacity: 420g
Minimum Display: 0.001g
Repeatability: 0.001g
Linearity: ±0.002g
Piece Counting Function
Operating Temperature: 5 – 40°C
Temp Coefficient Sensitivity (pmm/°C) (10 – 30°C): ±3
Pan Size (mm) approx.: 108w x 105
Main Body Dims (mm) approx.: 190w x 317d x 78h
Weight (kg) approx.: 3.4kg
Power Requirements: DC, 10 to 15.5 V, 500mA

Please fill out all required fields before adding to basket.


Approved for trade use the verified UW range of electronic balances are engineered with a UniBloc mechanism resulting in unrivalled response, stability and durability with a piece counting function for use within Pharmacy when counting tablets and capsules.

I want to upload measured data to a PC but installing the software is difficult…….. No Software Needed! The WindowsDirect function transmits data to a PC with just a cable. Achieve remarkable improvements in work efficiency with no additional investment, except for a cable. The standard auto print functions can be combined with the WindowsDirect function. I always need to weigh accurately but calibrating my balance is tedious…….. Easy calibration for every application Calibrations are automatically performed upon detection of a temperature change (UW). The balance automatically calibrates itself at the set times with its built-in calibration weights (UW). Calibrations can also be made at any time with a simple key operation (UW). Span calibration of the UX Series is easily performed by placing calibration weights on the balance according to the displayed instructions. I need to manage weighing according to international standards…….. Use the network-compatible software to ensure full compatibility with FDA 21 CFR Part 11. Fully-automatic calibration ensures accurate weighing (UW). Just connect an optional printer to automatically output time-stamped hard copies of calibration reports.

Adding CLASS-Agent Ver. 2.2, the network-compatible database registration and management tool, enables full compatibility with FDA 21 CFR Part 11 (Electronic Records, Electronic Signatures). I work in a drafty, dark environment…….. Adjust the balance to match the environment The display stability can be adjusted to the environment. Windbreak is provided as standard for models with a 1mg display, and is n option for other models. The auto zero function is useful in an environment where the TARE key must be pressed for every measurement. The back lighted display provides a clear display in dark environments. UniBloc Technology UniBloc one-piece force cell technology replaces the core mechanism of a high-precision balance with a single aluminium alloy lock. This provides a number of advantages, introducing fast response, high stability, and a long operational life.WindowsDirectFunctionOnly a single cable is required to transfer balance data to MS Excel®, or other Windows® applications. No interface attachment or software installation is necessary. This unique function makes interfacing Shimadzu balances extremely convenient.Automatic Touch-keyCalibration(UW only)Press just two keys to calibrate the balance whenever calibration is necessary. PSC Fully-automaticCalibrationIntroduced in 1985, this user-friendly feature triggers calibration when a temperature change is detected, automatically maintaining the balance’s sensitivity. Clock-CAL Fully-automaticCalibration Automatic calibration at pre-set times. Up to three times a day can be programmed. GLP/GMP/ISOCalibration Record Connect the optional printer to automatically output calibration results. Date and time are supplied by the balance’s built-in clock.Backlight LCD The backlight LCD display can be clearly read in the darkest of environments. Resolution 1/1,020,000 High-resolution models with a resolution of 1,020 g/1 mg can accurately detect minute changes in a large mass. Checkweighing Function When upper and lower thresholds are set, the balance indicates if the sample weight is within the range (GO), over (HI) or under (LO). Weigh-below hook The standard weight-below hook enables weighing on a user’s customized pan. Specific Gravity FunctionThe standard specific gravity measurement calculation function uses the Archimedes principle. Attaching the optional specific gravity measurement kit allows the balance to be used as a density meter or a hydrometer. Piece Counting A piece counting function is standard in addition to various unit conversions.

Additional information

Weight 3.4000 kg
Analog Bar Graph Display

Allows viewing of remaining capacity.


Easy to read in any environment.


Fully automated feature initiates self calibration at set time intervals, using motor driven internal calibration weight. Up to three automatic calibrations per day may be pre-set to coincide with work schedules or to meet specific quality goals.

Calibration Report

With optional printer connected to the balance, calibration reports which meet the requirements of GLP, GMP and ISO9000 can be produced.


Utilized in quality control applications.

Built-in Clock

Date and time can be readily supplied by the balance.

Specific Gravity Measurement

Software for specific gravity measurement is pre-installed. Simply add optional specific gravity kit for efficient measurements.

Standard Below-weigh Hook

Measurement beneath the balance is possible.

Internal Calibration

Calibration can be performed any time with a simple push o a button operation.

All-metal Housing

All metal construction for high durability.



Options container


Packed Dimensions(WxHxD mm)

585 x 260 x 370

Piece Counting Mode

Piece counting function is a standard feature.

Auto Print

Data can be automatically output as each measurement is made.

Product Dimensions (WxHxD mm)

191 x 79 x 317

Built-in RS-232C Interface

RS-232C interface is a standard feature.

Perfect Self Calibration

The balance self calibrates when it detects temperature change that would affect the accuracy. Operator is released form the constantly monitoring surrounding conditions.


Class ll

Interval Timer Output

Data can be automatically output as each measurement is made.


Single-block technology brings high performance and durability.

Packed Weight(Kg)



Weighed result is directly typed at the cursor positions of any application on Windows OS. No communication software is required.

Capacity (G/KG)


Weight (Kg)
